COMBINED MACHINE TRUMPF TRUMATIC 1000 – 1300 FIBER (K07) (FMC), 3000 WATT, KM-1167

Standard configuration

Machine
⦁ Closed machine frame
⦁ Hybrid axis system
⦁ Linear magazine with 20 spots for clamps and tools
⦁ Hydraulic clamps (3 pieces)
⦁ Drives with maintenance-free 3-phase servo motors
⦁ Repositioning unit with programmable stripper
⦁ Foot switch for closing clamps
⦁ Beam guard
⦁ Part chute right side
⦁ Part removal flap left side
⦁ Sensor for part removal flap
⦁ Work area illumination
⦁ FocusLine
⦁ SortMaster Compact retrofit capability

TRUMPF Laser
⦁ Solid state laser TruDisk 3001 with 1 laser output
⦁ Fiber optic cable according standard layout (10m)
⦁ Laser power control
⦁ Logbook function laser
⦁ Closed beam guidance via laser light cable (LLK)
⦁ Separate energy supply of TruDisk

Compact cutting unit
⦁ Solid-state compact cutting unit
⦁ Protective glas
⦁ Collision protection
⦁ ControlLine

Punching head
⦁ Delta Drive
⦁ Rotatable single tool adapter
⦁ Programmable position of the presser foot
⦁ Tool length compensation
⦁ Spray lubrication for punches
⦁ Vacuum slug removal
⦁ Forming
⦁ Stroke rate punch

Control
⦁ TRUMPF control based on Bosch Rexroth IndraMotion MTX
⦁ Control panel with TFT touch screen 19″
⦁ Integrated technology data
⦁ Programmable cutting gas pressure
⦁ Remote support interface
⦁ Automatic shutdown with Wakeup function
⦁ Program management
⦁ Production plan

Programming
⦁ TruTops Boost package
⦁ Data transfer
⦁ USB interface and network connection
⦁ Network connection RJ45
⦁ Central Link

Safety
⦁ CE marking
⦁ Double-beam safety light barrier

Advanced standard configuration
⦁ 1st index pin position right hand inner side
⦁ Process cooler (water-air)
⦁ Finished part container for part chute
⦁ Chip container
⦁ Compact dust extractor
⦁ Ball tables

Additional equipment

Extended laser equipment
⦁ Copper cutting package (includes cutting data O2 und N2)
⦁ Brass cutting package (includes cutting data N2)

Advanced punching equipment
⦁ Function MultiTool
⦁ Function MultiBend
⦁ Function Thread forming
⦁ Function marking / rapid beading
⦁ Adaptive stroke calibration
⦁ Smart Punch Monitoring
⦁ Die spray lubrication with monitoring of level

Discharge options
⦁ Integrated sorting function for part chute
⦁ Sensor for part chute
⦁ Small-part ejection
⦁ Deburring and rolling technology

Advanced machine equipment
⦁ Additional clamp

Automation

SheetMaster Compact 2500 x 1250 mm (AK05)
⦁ Suction frame
⦁ Double-sheet detection
⦁ Vacuum sensoric
⦁ Loading and unloading operator station
