PRESS BRAKE TRUMPF TRUBEND CELL 5170 S (B03), PM-1440

Standard configuration

Machine
⦁ Stable machine frame as all-steel construction
⦁ Spherical ram suspension, with ram tilt
⦁ Electro-hydraulic downstroking drive with 4-cylinder technology
⦁ Modern block hydraulics with control valves mounted on the cylinder
⦁ Electronic pressure balance
⦁ Measuring system
⦁ Hydraulic oil filled in the machine (lifetime lubrication)
⦁ Oil cooler
⦁ Switch cabinet cooling (air-air heat exchanger)
⦁ Modern machine design

Backgauge system
⦁ Backgauge system 2-axes
⦁ 2 pieces back gauge fingers

Tool holder
⦁ Manual upper tool clamping
⦁ Hydraulic lower tool clamping

Crowning
⦁ Manual crowning: integrated in the table, manual adjustable crowning via wedges

Lower Tool Adjustement
⦁ Lower tool adjustment CNC, programmable

Safety
⦁ Standard Safety Equipment

Control
⦁ TRUMPF TASC 6000
⦁ Network connection machine Control

Operation
⦁ Communication Track
⦁ Control panel: with LCD panel, footswitch für Emergency up, down and E-STOP

Additional equipment

Backgauge system
⦁ 6-axis backgauge System with switch cabinet air conditioning

Tool holder
⦁ Hydraulic upper tool clamping

Crowning
⦁ CNC crowning

Lower tool shifting
⦁ CNC lower tool shifting

Additional TruBend Options
⦁ Optical setup and positioning aid
⦁ Preparation ACB
⦁ Work area lighting rear
⦁ Work area lighting front
⦁ MobileControl

Automation

BendMaster
BendMaster (60) Standard configuration
Machine
– Stable frame and Manipulator
– Payload: max. 60 kg (gripper and blank weight), max. 40 kg (blank weight)
– Floor tracks: Length 6000 mm, travel 4550 mm
– Electrical drives
– Sheet sensor
– Rotary harness for easy Gripper Change
– Gripper coupling
– Sensors for 4-axis backgauge System
– Vacuum generation for suction Grippers
– NC gripper Station
Safety
– Safety fence with access door
Control
– TRUMPF PC with operating terminal
– Comfort Operation: monitor, mouse, Keyboard

Additional equipment BendMaster

Extended floor track
⦁ Extended floor track: 10000 mm

Material handling
⦁ Sensor for 6 axis back gauge
⦁ NC repositioning station
⦁ Double sheet detection
⦁ Automatic Gripper change module
⦁ TRUMPF Engineering

Mechanical finger Gripper Technology
⦁ Sheet loader with linear axis

BendMaster options
⦁ Door, rear for safety fence
⦁ Switch Cabinet air condition for BendMaster
