Standard configuration
Machine
⦁ Stable machine frame as all-steel construction
⦁ Ram, stress relief annealed
⦁ Spherical ram suspension, with ram tilt
⦁ Electro-hydraulic downstroking drive with 4-cylinder technology
⦁ Modern block hydraulics with control valves mounted on the cylinder
⦁ Electronic pressure balance
⦁ Measuring system
⦁ Hydraulic oil filled in the machine (lifetime lubrication)
⦁ Oil cooler
⦁ Switch cabinet cooling (air-air heat exchanger)
⦁ Modern machine design
Backgauge system
⦁ Backgauge system 2-axes
Tool holder
⦁ Manual upper tool clamping
⦁ Shifting: programmable
Crowning
⦁ Manual crowning: Integrated in the table, manual adjustable crowning via wedges
Lower Tool Adjustement
⦁ Lower tool adjustment CNC, programmable
Safety
⦁ Standard Safety equipment
Control
⦁ TRUMPF TASC 6000
Operation
⦁ Communication Track
⦁ Control panel: With LCD panel, footswitch für Emergency up, down and E-STOP
Additional Equipment
Backgauge System
⦁ 6-axis backgauge System with switch Cabinet air conditioning
Tool holder
⦁ Hydraulic upper tool clamping
Crowning
⦁ CNC crowning
Safety device
⦁ Safety device BendGuard (with Block-Laser)
⦁ Additional foot switch
Material handling
⦁ Front support brackets (2 pcs.)
⦁ Bending aid first arm
⦁ Table length extension (for one bending aid)
⦁ Parking position: 190 mm
Control
⦁ Mobile Control
Additional options TruBend
⦁ Work area lighting rear
