Standard configuration
Machine
⦁ Stable machine frame as all-steel construction
⦁ Ram, stress relief annealed: Highly resistant to torsional forces, of ample size
⦁ Spherical ram suspension, with ram tilt
⦁ Electro-hydraulic downstroking drive with 4-cylinder technology
⦁ Modern block hydraulics with control valves mounted on the cylinder
⦁ Electronic pressure balance
⦁ Measuring system: with centered glass scales and temperature compensation
⦁ Hydraulic oil filled in the machine (lifetime lubrication)
⦁ Control panel: with LCD panel, footswitch für Emergency up, down and E-STOP
⦁ Oil cooler
⦁ Switch cabinet cooling (air-air heat exchanger)
⦁ Modern machine design
Backgauge system
⦁ Backgauge system 2-axes
⦁ 2 pieces back gauge fingers
Tool holder
⦁ Manual upper tool clamping
⦁ Hydraulic lower tool clamping
Crowning
⦁ Manual crowning
Lower Tool Adjustement
⦁ Lower tool adjustment CNC, programmable
Safety
⦁ Standard Safety equipment: Emergency Stop button, manual roller shutter rear, protective panels, protective guards of transparent, impact-resistant plastic, CE certificate
Control
⦁ TRUMPF TASC 6000
⦁ Network connection machine control
Operation
⦁ Communication Track
⦁ Control panel: With LCD panel, footswitch für Emergency up, down and E-STOP
Additional equipment
Backgauge system
⦁ 4-axis backgauge system
Tool holder
⦁ Hydraulic upper tool clamping
Crowning
⦁ CNC crowning
Safety
⦁ Safety device BendGuard (with Block-Laser)
⦁ Additional foot switch
Material handling
⦁ 2 front support brackets
Additional options TruBend
⦁ Working area lighting, rear
⦁ Working area lighting, front
