Standard configuration
Machine
⦁ Stable machine frame as all-steel construction
⦁ Ram, stress relief annealed
⦁ Spherical ram suspension, with ram tilt
⦁ Electro-hydraulic downstroking drive with 4-cylinder technology
⦁ Modern block hydraulics with control valves mounted on the cylinder
⦁ Electronic pressure balance
⦁ Measuring system with centered glass scales and temperature compensation
⦁ Control panel with LCD panel, footswitch für Emergency up, down and E-STOP
⦁ Hydraulic oil filled in the machine (lifetime lubrication)
⦁ Oil cooler
⦁ Switch cabinet cooling (air-air heat exchanger)
⦁ Modern machine design
⦁ Backgauge system 2-axes
⦁ 2 pieces back gauge fingers
Tool holder
⦁ Manual upper tool clamping
⦁ Hydraulic lower tool clamping
Crowning
⦁ Manual crowning
Lower Tool Adjustement
⦁ Lower tool adjustment CNC, programmable
Safety
⦁ Standard Safety equipment: Machine safeguarded by means of Emergency Stop button, protective panels, CE certificate
Control
⦁ TRUMPF TASC 6000: Based on the Windows XPe operating system with 2.8 GHz and 2 redundant hard drives, 15“ Touch screen
⦁ Network connection machine control
Additional equipment
Machine options
⦁ Die space/stroke extension by 230 mm to 615 mm
Backgauge system
⦁ 5-axis backgauge system, switch cabinet air conditioning
Tool holder
⦁ Hydraulic upper tool clamping
Crowning
⦁ CNC crowning
Safety Device
⦁ Safety device BendGuard for 220 mm/s)
Material handling
⦁ 1 front support bracket
Additional options
⦁ ACB preparation
⦁ TruTops Bend control system with TruTops CAD
⦁ Long park position (900 mm for up to two bending aids)
